What are the Lash Series?
Lathe series machines are one of the types of metal lathes that are used to produce a large number of parts that are needed equally. You can easily categorize these devices, both in terms of form and size: • Manual lathe series machines • Semi-automatic lathe series machines • Automatic lathe series machines • Horizontal lathe series machines • Vertical lathe series machines
Depending on the type of performance of these machines, there are two types of pen machines:
Four-way pen holder
Six-sided pen holder
Six -way instrument device
In addition to face turning, screw turning, the six-sided tool holder device performs internal turning operations well.
way of setting up a six -way tool
In lathe series machines with a sliding mechanism that have a six-way tool holder, the tools are adjusted by means of special screws located at the other end of the drawer.
Because six tools are placed on the tool holder, as a result, there is an adjustment screw with a special breaker inside the device to adjust each tool.
Four -way tool tool
In this machine, face shaving operations such as: forehead shaving, step shaving, groove shaving and form shaving are performed consecutively with a four-way clamping tool. This device is placed on a transverse support (drawer) that moves across the machine. Four types of tools or graters are attached to this device.
Lash Machines in terms of instrumentation
Lathe series machines with the device for carrying the grater
Lathe series machine with longitudinal support device
series machines with a carrier carrier carrier
This type of machine is fast and very easy to operate. This type of machine is used for small lathes, complex works and ordinary works. The diameter of the work that can be cut with this type of machine is up to 75 mm and sometimes up to 500 mm, and the cutting length of the parts must be proportional to the length of the cutter, which usually varies from 100 mm to 330 mm. In this type of machine, the six-sided pen holder is placed on the roller, and the four-sided pen holder is placed on the car rail transversely and has a transverse movement.
Longing Machine with the longitudinal Sprout Machine
These types of machines are basically made in a large form and are intended for heavy and large turning works, especially works that are relatively long in terms of length and need to be cut accurately. With this type of machine, it is possible to cut works with a diameter of about 300 mm, and the works that must be closed in three systems have a diameter of about 900 mm. In these machines, the six-way grater device is closed directly on the saddle located on the rail and can be moved forward and backward along the length of the machine by means of the saddle. Fastening the six-sided pencil holder on the saddle directly maximizes the strength of the pen holder. In general, two types of turning (internal turning and surface turning) can be done with lathe series machines. Horizontal lathe series machines are usually used for turning.
Roller Lash machines
With the help of these devices, it is possible to produce a mass series of parts with fixed sizes in a shorter period of time than conventional lathes.
Types of Roulor Lash Machines
Manual roller turning machines
Automatic roller turning machines with NC and CNC control
how is the series?
• You choose the desired design and prepare its geometric model.
• The prepared geometric model must be transferred to the cnc machine software as G-Code data.
• At this stage, you should go to the control panel and enter your information in the form of coordinates.
• After completing the information on the control panel, pressing the start button will start the machine's engine.
• At the same time as the motor rotates, the spindle of the machine rotates at a high speed, which causes the axes to move.
• The movement of the axes finally results in the movement of the cutting tool, which performs the cutting process according to the coordinates determined on the control panel.
• Remember that you can set the spindle rotation speed and rotation direction in the control panel.
Factors that must be respected in lavish series
Setting time: the time when the person (operator) selects the tools and stabilizes the position
Time to close and perform operations on the workpiece: If the system is automatic, it is easier to perform
Machining time: The machining time of the part itself should take up most of the entire process, but at the same time it should be minimal
Tool cost: It is done according to the circulation of the work
Manpower cost
What is a CNC Shopping Series?
CNC turning series is an advanced and practical process for various industries. The cnc lathe implements a combination of numbers and codes and creates a connection between these numbers and codes. In this device, computers and robots are used to perform turning and engraving operations. This machine has created a huge transformation in various industries and the production and manufacturing processes of various parts become easier. CNC turning series is an advanced and practical process for various industries. The cnc lathe implements a combination of numbers and codes and creates a connection between these numbers and codes. In this device, computers and robots are used to perform turning and engraving operations. This device has created a huge transformation in various industries and the production and manufacturing processes of various parts become easier.
